The compressed air filter housing is mainly to filter and purify the compressed air ,is one of the common configurations of the after-treatment equipment of the air compressor.

Because the air inhaled by the air compressor contains impurities such as moisture and dust, some lubricating oil in the air compressor will become gas after compression. Therefore, the compressed air directly discharged by the air compressor contains water, oil and dust. If the compressed air containing the above impurities is directly delivered to the pneumatic system for use, the reliability of the pneumatic device system will be greatly reduced and the service life will be shortened. Therefore, it is very necessary to use compressed air filters in the whole air compressor system .

Our Thailand customers regularly purchase such filter for their textile mill factory , specific info as follow .

1.Carbon steel shell

2.4 '' flange connection

3.Operating temperature: max. 80 ℃ min. 2 ℃

4.Working pressure :12bar

5.Flow: 3300nm ³/ h (55000nl/min)

6.Height: 1131mm

Diameter: 550mm

Distance from flange connection center to shell bottom Height: 935mm

7.With pressure gauge and manual drain valve

If you have special request , Aida tech engineer also can design for you , my friend .
