The droplets of oil, water and other liquids are captured by the microfibers inside the coalescer. These microfibers form zigzag channels for the air flow, forcing the solid particles and liquid droplets to be captured by the microfibers under the action of three filtration mechanisms: inertial collision, diffusion interception and direct interception. The surface tension of the liquid makes the small droplets aggregate into larger droplets. Due to the effect of gravity, the large droplets settle to the bottom of the container.

Coalescence filter element has good compatibility with various fluids. The filter element is spiral wound with multi-layer structure, and fibers with different properties are used for each layer. The expected filtering accuracy can be achieved by controlling the shape, size, thickness, density and other parameters of each layer of fibers.

Main features

1. High density gradient glass fiber, which effectively coalesces liquid mist and droplets in the gas flow, with high filtration accuracy.

2. Stable structure, no medium fiber falling off, no pollution to the environment and downstream products

3. It has good compatibility with various fluids;

4. Good environmental protection, 100% synthetic material, complete combustion and no residue. It is made of a variety of composite materials through special processing

With hydrophilic characteristics, it can not only filter out mechanical impurities in the medium, but also demulsify and coalesce.

Main application

1. Metallurgy: used for filtration of hydraulic system of rolling mill and continuous caster and filtration of various lubricating equipment.

2. Petrochemical: separation and recovery of products and intermediate products in the process of oil refining and chemical production, liquid purification, purification of magnetic tapes, optical discs and photographic films in the manufacturing process, particle removal and filtration of oilfield injection water and natural gas.

3. Aviation fuel, gasoline, kerosene and diesel;

4. Turbine oil and other low viscosity hydraulic oil and lubricating oil;

5. Special dust removal filter element for dust collection box of engineering drilling rig, etc

Advantages

1. The filter paper with multi-layer composite structure has high filtering accuracy;

2. The carefully set and specially treated glass fiber layer has good coalescence effect.

3. High flow density and reduced fine filter size;

4. Large sewage capacity and long service life;

5. Complete specifications and varieties can meet the needs of various fine filters.

Coalescing filter element has dual functions of filtering impurities and coalescing water from aviation kerosene, and is an important functional element of fine filter. It can meet the needs of various fine filters used in fixed and mobile refueling facilities.

Customer case

New customers from Pakistan place orders for coalescing filter elements. The company mainly undertakes equipment maintenance and filtration of hydraulic system. The use of coalescing filter elements can filter out impurities in the media to a greater extent. At the same time, our factory produces and manufactures according to the size of customers, which cooperates with customers' projects to a greater extent.
