Product Details
Details:
Filtration Group Surface filter elements are made of stainless steel wire mesh with a very low flow resistance designed in the following weaves: plait, twill and linen. For a wire mesh filter element the degree of filtration is determined by the largest diameter of a globular particle which would be able to pass the fabric. Wire mesh filter elements are used in hydraulic oil and lubricants filtration as suction or coarse filters, for high viscous fluids as well as safety filters for coolant filtration. Wire mesh elements possess a defined removal size as surface filter and a low dirt holding capacity as depth filter. These filter elements can be used in Filtration Group filter housings as well as customized to meet the specifications of other manufacturers' housings.
Cleanable surface filter element, made of wire mesh
Designed for Filtration Group filter housings
Complete product range according DIN 24550
Beta rated elements according to ISO 9001 multipass test
Elements with high differential pressure stability and dirt holding capacity

Parameter:
Model number:PI8205 DRG25
Dimensions
Outer Diameter (in):1.85 in. Outer Diameter (mm):47 mm
Flow Rate (gallons/minute):13.21 gal/min Flow Rate (liters/minute):50 l/min
Height(in):3.66 in. Height (mm):93 mm
Performance Specifications
Micron Rating:25µ
Temperature Rating:-10°C to +120°C
Differential Pressure (PSI):290.08 PSI
Differential Pressure (bar):20 bar
Additional Specifications
Media Material:Wire Mesh
Endcap:Metal
Sealing Function:Radial
